Harken
57mm Aluminum Footblock
57mm Aluminum Footblock
Regular price
$553.77 AUD
Regular price
Sale price
$553.77 AUD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Use footblocks to redirect lines on the deck. Footblocks with lookoffs temporarily secure sheets. Either metric or imperial flathead fasteners may be used for mounting and are not exposed. Sideplates and sheaves Hard Lube-anodized for maximum UV protection and a smooth surface. Center cage keeps Torlon® roller bearings separated and parallel to reduce friction. Torlon is a registered trademark of Solvay Advanced Polymers L.L.C.
Specifications
| Part Number | 3220 | 3234 | 3249 |
| Sheave Ø (mm) | 57 mm | 75 mm | 100 mm |
| Length (mm) | 84 mm | 111 mm | 143 mm |
| Weight (g) | 122 g | 277 g | 555 g |
| Maximum line Ø (mm) | 12 mm | 14 mm | 16 mm |
| Fasteners (mm) | 6 FH mm | 8 FH mm | 10 FH mm |
| Maximum working load (kg) | 1134 kg | 2380 kg | 3402 kg |
| Breaking load (kg) | 2268 kg | 4762 kg | 6804 kg |
| Height (mm) | 25 mm | 32 mm | 33 mm |
| Number of fasteners | 4 | 4 | 4 |
| A (mm) | 9.5 mm | 11.5 mm | 14.5 mm |
| B (mm) | 22.5 mm | 28.5 mm | 37.5 mm |
| C (mm) | 51.5 mm | 70.5 mm | 92.5 mm |
| D (mm) | 16 mm | 21 mm | 28 mm |
| E (mm) | 59 mm | 77 mm | 100 mm |
| F (mm) | 84 mm | 110 mm | 143 mm |
| G (mm) | 13 mm | 17 mm | 23 mm |
